Opera System Milling Machine Element optimizes your digital workflow, enjoy maximum freedom and achieve optimal results.

Opera System
Milling Machine
Element

DRY MILLING 5 AXIS

Optimize your digital workflow, enjoy maximum freedom and achieve optimal results.

No Compresses Air, 5 Axis, 1 Blank, 6 Blocks, 17 Tools, Dry.

CONTACT US

HIGH MACHINING SPEED FOR A PERFECT RESULT

  • Disc thickness up to 40 mm

  • 5 axis dry milling

  • Optimal use of blanks

  • Automatic tool changer 17 tools

  • Option: 6 blocks holder

  • Color coded tools

HIGH MACHINING SPEED FOR A PERFECT RESULT, Disc thickness up to 40 mm 5 axis dry milling.

Data Sheet

Fields of application
Dry machining
Rotation Speed
up to max 60,000 RPM
Repetition accuracy
± 5 microns
No compressed air
AIRTOOL patent
Positioning Range
A rotary axis of 360 degrees – B rotary axis (fifth axis) of ± 35 degrees
Machinable materials
Zirconia, Wax, PMMA, Peek, Acetal, nanoceramic
Automatic Tool Changer
7 tools
Blank thickness
10 a 40 mm Ø 98,5 mm
No. of axes
5
File Format
STL
Weight
472 x 484 x 734 mm chiuso – 472 x 567 x 734 mm aperta
Dimensions
± 43 kg
Product Inquiry

Request for quotation
